Flat-head screw with internal Torx, stainless steel
Type 7380T M6x20 A2
|Item no. 3164972
|EAN 4012196101047
Item no. / Type
3164972 / 7380T M6x20 A2
Length
20 mm
Thread
M6
Smallest selling unit: 100 piece
100piece
piece
Description
Flat head screw with TX 30, according to ISO 7380-1, suitable for fastening cable routes on brackets as well as for the mounting of barrier strips. The rounded head shape provides optimum cable protection. The Torx drive offers optimum force transmission in the screw movement.
Technical data
Dimensions
| Length | 20 mm |
|---|
Technical data
| Thread metric | 6 |
|---|---|
| Thread | M6 |
| Screw system | Torx |
| Dimension | M6x20 |
| Dimension | M6x20mm |
| Surface | Bright, treated |
| Material | Stainless steel |
Environmental Data
0,028 kg CO2e / 1 PieceCO2 Footprint (GWP) Cradle-to-Gate
| Packaging without plastic | yes |
|---|
| CO2 Footprint (GWP) Cradle-to-Gate | 0,028 kg CO2e / 1 Piece |
|---|
Downloads
0 selected
Data sheet (1)
Catalogues & Flyers (1)
Declarations (2)
Product images (2)
Tender specifications (1)
Variants
Type
Length
Thread
Item no.
7380T M6x20 A2
20
M6
3164972
7380T M6x20 A2
Item no.
3164972
Length
20
Thread
M6
