Universal bi-metal separating piece, Rd 16 A2, Rd 8-10 copper

Universal bi-metal separating piece, Rd 16 A2, Rd 8-10 copper

Type 226 ZV VA
|
Item no. 5336074
|
EAN 4012195424390
Show all variants
Item no. / Type
5336074 / 226 ZV VA
Fit
Rd 8-10/FL30 x 16 mm

Smallest selling unit: 10 piece

piece

Description

• Fit: Rd 8-10 x 16, FL 30 x Rd 16
• With 2 hexagonal bolts M8 x 20, stainless steel (VA)
• Intermediate plate, aluminium/copper
  • CO₂ footprint (PCF)
  • Packaging without plastic
  • Packaging made entirely from recycled cardboard

Technical data

Technical data

Intermediate plateyes
Bimetal connectoryes
Suitable for connectionRound conductor Rd 16 / flat conductor Fl 30
Material lower partCu
Material upper partVA
FitRd 8-10/FL30 x 16 mm
DimensionFL30/8-10x16
MaterialCopper

Environmental Data

0,6859 kg CO2e / 1 PieceCO2 Footprint (GWP) Cradle-to-Gate
Packaging made completely from recycled cardboard.yes
Packaging without plasticyes
CO2 Footprint (GWP) Cradle-to-Gate0,6859 kg CO2e / 1 Piece

Downloads

0 selected

Data sheet (1)
Catalogues & Flyers (3)
Declarations (3)
Product images (3)
3D data downloads (2)
Tender specifications (1)

Variants

226 ZV VA
Item no.
5336074
Fit
Rd 8-10/FL30 x 16
