Bundle clip A2
Item no. 1194372 | EAN 4012195476771
- Product description
-
Product descriptionClip and bolt made of hot-dip galvanised steel, countersunk head bolt made of rustproof stainless steel, slide nut made of electrogalvanised stainless steel.
Stainless steel version: clip and screw made of hot-dip galvanised steel, slide nut, type 5019, made of rust-proof stainless steel.
-
- Technical data
-
Technical data
CO2 Footprint (GWP) Cradle-to-Gate 1,8282 kg CO2e / 1 Piece Dimension 80x100mm Dimension B 100 mm Dimension H 80 mm Dimension h 55 mm for rail with slot width (with interval), max. 16 mm for rail with slot width (with interval), min. 17 mm Halogen-free no Material Stainless steel 1.4301 Material addition Steel Mounting type Profile rail Surface Bright, treated Surface addition hot galvanised With metal trough yes With plastic trough no - All types
- Downloads
-
Data sheet 2056 B 80 A2 / 1194372 , 0.20MB , pdfEU declaration of conformity 2056 B 80 A2 / 1194372 , 0.10MB , pdfUK Declaration of Conformity 2056 B 80 A2 / 1194372 , 0.09MB , pdfREACH Declaration of conformity 2056 B 80 A2 / 1194372 , 0.12MB , pdfRoHS Declaration of conformity 2056 B 80 A2 / 1194372 , 0.13MB , pdf
