Cable gland, metric thread, set with locknut, light grey
Type V-TEC VM12+ LGR
|Item no. 2022762
|EAN 4012195860921
Item no. / Type
Vida dişi
Smallest selling unit: 50 piece
50piece
piece
Description
Cable gland with metric connection thread in cap nut design, suitable for junction boxes, housings, distributor cabinets in private and industrial areas. With strain relief and integrated sealing lip, tested according to DIN EN 62444. Protection class IP68. Can be used between –20°C and +65°C. Including locknut.
Technical data
Technical data
| Darbeye dayanıklı | hayır |
|---|---|
| Halojen İçermez | evet |
| Cam elyafı takviyeli | hayır |
| Patlamaya karşı korumalı | hayır |
| Çekme yükü azaltma imkanı | evet |
| Koruma sınıfı | IP68 |
| Vida dişi | M12 x 1,5 |
| For Ex zone | Yok |
| Thread type | Metric |
| Bend protection | hayır |
| With locknut | hayır |
| Sealing insert, multiple | hayır |
| Flat cable gland | hayır |
| Type of seal | Sealing ring |
| Splittable gland | hayır |
| For Ex zone gas | Yok |
| For Ex zone dust | Yok |
| Thread increase | 1,5 mm |
| Nominal thread size | 12 |
| Sızdırmazlık alanı D min. | 3,5 mm |
| Sızdırmazlık alanı D maks. | 7 mm |
| Ölçü E1 (mm) | 16,5 mm |
| Dimension E2 | 19 mm |
| Version for | Düz |
| Vida dişi uzunluğu | 8 mm |
| WAF 1 | 15 mm |
| WAF 2 | 17 mm |
| Unstable torque | 2 Nm |
| Kullanılabilir sıcaklık aralığı min. | -20 °C |
| Kullanılabilir sıcaklık aralığı maks. | 65 °C |
| Aleve dayanıklı | acc. to VDE 0471/DIN 695 Part 2-1, test temperature 650°C |
| Boyut | M12 |
| Material | Polyamide |
| Colour | Light grey; RAL 7035 |
Dimensions
| Dimension L min. | 18,5 mm |
|---|---|
| Dimension L max. | 23,5 mm |
| Dimension L1 | 8 mm |
| Dimension L2 | 5 mm |
| Dimension L3 | 5 mm |
Environmental Data
| Packaging without plastic | evet |
|---|
| CO2 ayak izi (GWP) beşikten kapıya | 0,0255 kg CO2e / 1 Adet |
|---|
Downloads
0 selected
Data sheet (1)
Catalogues & Flyers (2)
Declarations (4)
Certificates (3)
Product images (2)
Tender specifications (1)
Variants
Type
Vida dişi
Sealing insert, multiple
Colour
Item no.
V-TEC VM12+ LGR
M12 x 1,5
hayır
Light grey; RAL 7035
2022762
V-TEC VM16+ LGR
M16 x 1,5
hayır
Light grey; RAL 7035
2022764
V-TEC VM20+ LGR
M20 x 1,5
hayır
Light grey; RAL 7035
2022766
V-TEC VM25+ LGR
M25 x 1,5
hayır
Light grey; RAL 7035
2022768
V-TEC VM32+ LGR
M32 x 1,5
hayır
Light grey; RAL 7035
2022770
V-TEC VM40+ LGR
M40 x 1,5
hayır
Light grey; RAL 7035
2022772
V-TEC VM50+ LGR
M50 x 1,5
hayır
Light grey; RAL 7035
2022774
V-TEC VM63+ LGR
M63 x 1,5
hayır
Light grey; RAL 7035
2022776
