Cap nut cable gland, metric thread, silver grey

Cap nut cable gland, metric thread, silver grey

Type V-TEC VM12 SGR
|
Item no. 2022843
|
EAN 4012195532637
Show all variants
Item no. / Type
Vida dişi

Smallest selling unit: 50 piece

piece

Description

The quickest and most convenient way of providing strain relief and tightness with cable glands on junction boxes and housings is with the tried-and-trusted V-TEC VM cable glands from OBO. With the integrated sealing lip and the special OBO lamella technology, protection class IP68 is achieved. Strain relief and tightness have been tested to DIN EN 62444.
The connecting threads of the cable glands are metric or PG and are therefore suitable for universal use. Once screwed in place, the installation is there forever, as the optimum thread adjustment with the right pitch ensures permanent resistance to shaking.
Applications: From private housing with junction boxes up to industrial applications in the distributor cabinet.
Temperature range: –20 °C to +65 °C.
  • Underwriters Laboratories Inc., USA + CSA, Kanada
  • Det Norske Veritas
  • Alman Elektrik, Elektronik ve Bilgi Teknolojileri Birliği
  • Aleve dayanıklı 650°C
  • Communautés Européennes, AB Yönetmelikleri uyarınca AB Uygunluk Beyanı
  • UKCA declaration of conformity
  • Koruma sınıfı IP 68
  • Metrik vida dişi
  • CO₂ footprint (PCF)
  • Packaging without plastic

Technical data

Technical data

Darbeye dayanıklıhayır
Halojen İçermezevet
Cam elyafı takviyelihayır
Patlamaya karşı korumalıhayır
Çekme yükü azaltma imkanıevet
Koruma sınıfıIP68
Vida dişiM12 x 1,5
For Ex zoneYok
Thread typeMetric
Bend protectionhayır
With locknuthayır
Sealing insert, multiplehayır
Flat cable glandhayır
Type of sealSealing ring
Splittable glandhayır
For Ex zone gasYok
For Ex zone dustYok
Thread increase1,5 mm
Nominal thread size12
Hexagonal corner dimension16,5 mm
Sızdırmazlık alanı D min.3,5 mm
Sızdırmazlık alanı D maks.7 mm
WAF15
Version forDüz
Vida dişi uzunluğu8 mm
Unstable torque2 Nm
Kullanılabilir sıcaklık aralığı min.-20 °C
Kullanılabilir sıcaklık aralığı maks.65 °C
Aleve dayanıklıacc. to VDE 0471/DIN 695 Part 2-1, test temperature 650°C
BoyutM12
MaterialPolyamide
ColourSilver grey; RAL 7001

Dimensions

Dimension L min.18,5 mm
Dimension L max.23,5 mm
Dimension L18 mm
Dimension L25 mm
Dimension E16,5 mm

Environmental Data

Packaging without plasticevet
CO2 ayak izi (GWP) beşikten kapıya0,0189 kg CO2e / 1 Adet

Accessories

Mounting accessories
Type
116 M12 SGR PA

Smallest selling unit: 100 piece

piece

Downloads

0 selected

Data sheet (1)
Catalogues & Flyers (4)
Declarations (4)
Certificates (5)
Instructions and Aid (1)
Product images (2)
3D data downloads (1)
Tender specifications (1)

Variants

Vida dişi
V-TEC VM12 SGR
Item no.
2022843
Vida dişi
M12 x 1,5
Sealing insert, multiple
hayır
Colour
Silver grey; RAL 7001
V-TEC VM16 SGR
Item no.
2022845
Vida dişi
M16 x 1,5
Sealing insert, multiple
hayır
Colour
Silver grey; RAL 7001
V-TEC VM20 SGR
Item no.
2022847
Vida dişi
M20 x 1,5
Sealing insert, multiple
hayır
Colour
Silver grey; RAL 7001
V-TEC VM25 SGR
Item no.
2022849
Vida dişi
M25 x 1,5
Sealing insert, multiple
hayır
Colour
Silver grey; RAL 7001
V-TEC VM32 SGR
Item no.
2022851
Vida dişi
M32 x 1,5
Sealing insert, multiple
hayır
Colour
Silver grey; RAL 7001
V-TEC VM40 SGR
Item no.
2022853
Vida dişi
M40 x 1,5
Sealing insert, multiple
hayır
Colour
Silver grey; RAL 7001
V-TEC VM50 SGR
Item no.
2022855
Vida dişi
M50 x 1,5
Sealing insert, multiple
hayır
Colour
Silver grey; RAL 7001
V-TEC VM63 SGR
Item no.
2022857
Vida dişi
M63 x 1,5
Sealing insert, multiple
hayır
Colour
Silver grey; RAL 7001
